Examples custom hinges

Would you like a quotation for your custom-made hinge? Or inquire about the possibilities? Send us your working drawing or design and any specifications for a quote. We will be happy to get to work for you.

Upload your working drawing

A selection of our custom hinges

Request your own special hinge now

At BOSCH Hinges, the possibilities are endless. We can design your custom hinges entirely to suit the needs of your project.

Don’t see what you are looking for? Send us your design or wishes and we will inform you about the possibilities.

Upload working drawing

High quality material and coating

From stainless steel to aluminium. From galvanizing to powder coating. After the selection of your type of hinge, BOSCH Hinges offers various possibilities for the optimization of your hinge. For example to make it corrosion resistant.

Knuckle

The hinge knuckle is the circular part. Also called bead or loop. The knuckles of the two different clasps usually alternate around the pen.

1 of 10
Pin

The pin connects the two (or more) hinge leafs.

2 of 10

The pin diameter determines the thickness of the pin, measured in diameter.

3 of 10
Leaf

The leaf or blade of the hinge is the rotating or fixed part of a hinge.

4 of 10

The leaf width is the distance from the end of the leaf to the center of the pin.

5 of 10

The leaf thickness is the thickness of the hinge.

6 of 10

The hinge width is the total width of the open hinge: measured at right angles to the pin.

7 of 10

The knuckle length is the length from one end to the other end of a single knuckle, parallel to the pin. Usually this is a fixed size, e.g. 30mm, 25mm, 20mm, etc.

8 of 10

The end play is the light axial movement between the knots over the axis of the pen. This is caused by the small space between the nodes, which causes the leaf to hinge.

9 of 10

The hinge length is the total length of the hinge measured over the leaf parallel to the pin.

10 of 10

Jacco

Commercial Technical Advisor

“Success is realizing the right solution for each customer”

Need help finding the right hinge?

We are happy to help you. Send a message via the chat pop-up or call or email us for more information and advice.

Logo BOSCH Scharnieren maatwerk Nederland

wij denken met u mee.

BOSCH Scharnieren levert maatwerk scharnieren voor de industrie. Neem contact op voor een offerte of passend advies.

Zakelijk
Particulier

Vouwscharnier voorbeeldnr. 159470

Soort scharnier: vouwscharnier
Materiaal: RVS 304 – Wn 1.4301

Upload direct uw scharniertekening:

BOSCH Scharnieren is de specialist in maatwerkscharnieren met korte levertijden. Stel uw offertevraag in het veld hieronder of deel uw werktekening en eventuele specificaties voor een offerte. Wij helpen u graag uw project realiseren.

BOSCH Scharnieren is de specialist in maatwerkscharnieren met korte levertijden. Stuur ons uw werktekening of ontwerp en eventuele specificaties voor een offerte. Wij helpen u graag uw project realiseren.

Logo BOSCH Scharnieren maatwerk Nederland

wij denken met u mee.

BOSCH Scharnieren levert maatwerk scharnieren voor de industrie. Neem contact op voor een offerte of passend advies.

Zakelijk
Particulier
Logo BOSCH Scharnieren maatwerk Nederland

We help you find solutions

BOSCH Hinges supplies custom hinges for the industry. Please contact us for a quotation or appropriate advice.

Business
Private

Upload your working drawing

BOSCH Hinges is the specialist in customized industrial hinges with short delivery times. Send us your working drawing or contact us directly in the field below to discuss the possibilities. We are happy to help you realize your project.

BOSCH Scharnieren is de specialist in maatwerkscharnieren met korte levertijden. Stuur ons uw werktekening of ontwerp en eventuele specificaties voor een offerte. Wij helpen u graag uw project realiseren.

Vouwscharnier voorbeeldnr. 159470

Soort scharnier: scharnier met vouw
Materiaal: RVS 304 – Wn 1.4301

Profile hinge example nr. 106

Hinge type: profile hinge

Material: Sendzimir

Dimensions: 60x200x6mm pin ø8mm

Sendzimir steel profile hinge. Sendzimir pre-galvanized steel provides additional anti-corrosion properties.

Rolled hinge example nr. 11

Hinge type: rolled hinge

Material: stainless steel 304

Dimensions: 140x71x2mm pin ø6mm

Stainless steel rolled hinge with riveted pin.

Rolled lift-off hinge example nr. 79

Hinge type: rolled lift-off hinge, rolled hinge

Material: stainless steel 304

Dimensions: 120x33x2mm pin ø6mm right

Stainless steel rolled lift off hinge with serrated pin

Spring hinge example nr. 104

Hinge type: spring hinge, rolled hinge

Material: stainless steel 304

Dimensions: 155x32x1mm pin ø2mm

Rolled hinge example nr. 12

Hinge type: rolled hinge

Material: stainless steel 304

Dimensions: 59x40x1,5mm pin ø3mm

Stainless steel rolled hinge, polished and unassembled

Continuous hinge example nr. 62

Hinge type: continuous hinge, rolled hinge

Material: stainless steel 304

Dimensions: 630x50x2mm pin ø6mm

Stainless steel continuous hinge, carved

Overlay hinge example nr. 13

Hinge type: overlay hinge, rolled hinge

Material: steel

Dimensions: 264×65,5×1,5mm pin ø4mm

Steel hinge with a fold and perseverance.

Single hinge part example nr. 100

Hinge type: single hinge part, rolled hinge

Material: stainless steel 304

Dimensions: 60×88,5×3,0mm, pinhole ø 7,0mm

Stainless steel Hinge part for a manufacturer of air systems for transport and industry

Lift-off hinge example nr. 14

Hinge type: rolled lift-off hinge

Material: Sendzimir

Dimensions: 40x41x3mm pin ø6mm

Sendzimir steel hinge with fold for a manufacturer of industrial packaging. The pin is made of stainless steel 316 for riveting. Sendzimir pre-galvanized steel provides extra anti-corrosion properties.

Spring hinge example nr. 15

Hinge type: spring hinge, rolled hinge

Material: Sendzimir

Dimensions: 745x151x2,0mm, pin ø4,0mm

Sendzimir steel spring hinge, contra mounted. Sendzimir pre-galvanized steel provides additional anti-corrosion properties.

Rolled hinge example nr. 16

Hinge type: rolled hinge

Material: stainless steel 304

Dimensions: 200x50x1,5mm pin ø3mm

Stainless steel rolled hinge for aircraft construction with countersunk holes

Overlay hinge example nr. 17

Hinge type: overlay hinge, rolled hinge

Material: stainless steel 304

Dimensions: 70x82x4mm pin ø8mm

Stainless steel rolled hinge with fold for heavy doors. This strong hinge is ideally suited for offshore applications. With compression bolt, fold, grease nipple and serrated pin.

Rolled hinge example nr. 18

Hinge type: rolled hinge

Material: stainless steel 304

Dimensions: 140x71x2mm pin ø6mm

Stainless steel rolled and riveted hinge.

Coated hinge example nr. 86

Hinge type: coated hinge, single hinge part, square hinge

Material: stainless steel 304

Dimensions: 40x30x2mm for pin ø4mm

Stainless steel square hinge (fits), seperate hinge part with coating.

Overlay hinge example nr. 9

Hinge type: overlay hinge, rolled hinge

Material: stainless steel 304

Dimensions: 65x69x2mm pin ø4mm right

Stainless steel rolled hinge with riveted pin and ground surface, the hinge holes are finished.

Rolled hinge example nr. 19

Hinge type: rolled hinge

Material: stainless steel 304

Dimensions: 100x65x2mm pin ø4mm

Stainless steel rolled and clamped hinge.

Overlay hinge example nr. 90

Hinge type: overlay hinge, creative hinge

Material: stainless steel 304

Dimensions: 128,5×96,5x1mm pin ø3mm

Stainless steel hinge with fold for aircraft construction (airbus). This creative hinge with clamping ring is welded, engraved and polished.

Rolled hinge example nr. 20

Hinge type: rolled hinge, overlay hinge

Material: stainless steel 304

Dimensions: 50x40x1,25mm pin ø2,5mm

Square hinge example nr. 73

Hinge type: square or rectangular hinge, overlay hinge, single hinge part

Material: stainless steel 304

Dimensions: 58x25x3mm for pin ø8mm

This stainless steel hinge part was delivered unassembled on request to a manufacturer of transformer houses. This fits with fold is used to connect the metal doors to the concrete hull. In addition to the precise finish, the long service life is especially important. After a change in construction, we now also deliver the hinge fully assembled. Please ask for article no. 159869.

Multi link hinge example nr. 88

Hinge type: multi link hinge, creative

Material: stainless steel 304

Dimensions: 90x90x2,5mm pin ø5mm

Stainless steel multi-piece hinge, clamped.

Rolled hinge example nr. 21

Hinge type: rolled hinge, overlay hinge

Material: stainless steel 304

Abmessung: 70x82x4mm pin ø8mm

Stainless steel rolled hinge with fold for heavy doors. This strong hinge is ideally suited for offshore applications. With compression bolt, fold, grease nipple and serrated pin.

Rolled hinge example nr. 22

Hinge type: rolled hinge

Material: steel

Dimensions: 95x65x3mm pin ø6mm

Steel rolled hinge, contra mounted.

Rolled hinge example nr. 23

Hinge type: rolled overlay hinge

Material: Sendzimir

Dimensions: 60×68,5×1,5 pin ø4mm

Sendzimir steel hinge with fold. Sendzimir pre-galvanized steel provides additional anti-corrosion properties.

Continuous hinge example nr. 63

Hinge type: continuous hinge, rolled hinge

Material: steel

Dimensions: 1050x150x3mm pin ø6mm

Joint hinge example nr. 158432

Hinge type: joint hinge with fold

Material: stainless steel 304

Dimensions: 61x34x2mm pin ø4mm right

Stainless steel joint hinge with fold, riveted.

Cabinet door hinge example nr. 158733

Hinge type: cabinet door hinge, butt hinge

Material: stainless steel 304

Dimensions: 42x132x2mm pin ø5mm with lock hook

Stainless steel cabinet door hinge with lock. This hinge with fold is continued and also suitable as a flap hinge.

Rolled hinge example nr. 24

Hinge type: rolled overlay hinge

Material: stainless steel 306

Dimensions: 180x57x2, pin ø5,0mm

Stainless steel hinge with fold, used for monitor suspension in a control room. The hinge has a serrated pin.

Rolled hinge example nr. 10

Hinge type: rolled hinge

Materiaal: stainless steel 304

Dimensions: 40x56x31x3mm pin ø6mm

Stainless steel rolled hinge with plunge cutout

Rolled hinge example nr. 8

Hinge type: rolled hinge

Material: stainless steel 304

Dimensions: 130x160x1mm pin ø2mm

Stainless steel rolled hinge, clamped.

Continuous hinge example nr. 65

Hinge type: continuous hinge, rolled hinge

Material: stainless steel 304

Dimensions: 1126×60,3x3mm pin ø6mm

Stainless steel contra mounted continuous hinge.

Continuous piano example nr. 60

Hinge type: continuous piano, rolled hinge

Material: Stainless steel 304

Dimensions: 1198x40x1,5mm pin ø3mm

Stainless steel piano hinge with sovereign hinge holes.

Gerold scharnier voorbeeldnr. 159374

Soort scharnier: gerold scharnier
Materiaal: RVS 304 – Wn 1.4301

Kastdeurscharnier voorbeeldnr. 159296

Soort scharnier: kastdeurscharnier
Materiaal: RVS 304 – Wn 1.4301

Deurscharnier voorbeeldnr. 159508

Soort scharnier: deurscharnier
Materiaal: RVS 304 – Wn 1.4301

Single hinge part square hinge example nr. 67

Hinge type: single hinge part square hinge

Material: steel

Dimensions: 195x22x1,5mm for pin ø8mm

Steel hinge part galvanized after production for machine and equipment construction.
